Description
View online Operation & user’s manual for HIKVISION DS-7600 Network Hardware or simply click Download button to examine the HIKVISION DS-7600 guidelines. May 29, 2018 Amazon.com: HIKVISION DS-7616NI-E2/16P 16-CH & 16-PoE Network Video Recorder Embedded Plug & Play NVR: Camera & Photo. Page 1 DS-7604NI-E1/4P DS-7608NI-E2/8P DS-7616NI-E2/16P NVR USER’S MANUAL Version 3.3.2.; Page 2 The content of this manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Hikvision Digital Technology Co., Ltd. Hikvision assumes no responsibility or liability for any errors or inaccuracies that may.
Share the post 'DS-7616NI-E2/8P'
| Model | DS-7616NI-E2/8P |
|---|---|
| IP video input: | 16-ch |
| Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Incoming bandwidth: | 160Mbps |
| Outgoing bandwidth: | 80Mbps |
| Remote connection: | 128 |
| HDMI/VGA output: | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Recording Resolution: | 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate: | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
| Synchronous Playback: | 16-ch |
| Live view / Playback: | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: | 6-ch@1080P |
| SATA: | 2 SATA interfaces for 2 HDDs |
| Capacity: | Up to 6TB capacity for each HDD |
| Network Interface: | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| USB Interface: | 1 × USB 2.0 and 1 × USB 3.0 |
| Alarm In: | 4-ch(optional) |
| Alarm Out: | 1-ch(optional) |
| Interface: | 8 independent 100 Mbps PoE network interfaces |
| Max. Power: | 120W |
| Supported Standard: | AF and AT |
| Power Supply: | 100~240VAC |
| Consumption(without hard disk and POE): | ≤ 10W |
| Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: | 10 % ~ 90 % |
| Chassis: | 19-inch rack-mounted 1U chassis |
| Dimensions: | 445 × 290 × 45mm (17.5 ×11.4 × 1.8 inch) |
| Weight(without HDD): | ≤ 1 Kg (2.2 lb) |
DS-7600NI-I2 /P Series NVR Available Models DS-7608NI-I2/8P, DS-7616NI-I2/16P, DS-7632NI-I2/16P Key Features Professional and Reliable Dual-OS design to ensure high reliability of system running ANR technology to enhance the storage reliability when the network is disconnected. Page 1 Network Video Recorder User Manual UD01084B.; Page 2 (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. NVR Comparison Chart. A quick reference chart that outlines the differences between the various Hikvision NVR products. NVR Comparison Chart. May 05, 2017 Amazon.com: HIKVISION 16CH 16 Ports PoE DS-7616NI-E2/16P NVR Network Video Recorder with up to 5MP Resolution Recording Includes a 4TB Hard Drive: Camera & Photo.
Description
Ds-7616ni-e2 8p User Manual Online
| Video/Audio Input | ||
|---|---|---|
| IP video input: | 8-ch | |
| Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) | |
| Network | ||
| Incoming bandwidth: | 80Mbps | |
| Outgoing bandwidth: | 80Mbps | |
| Remote connection: | 128 | |
| Video/Audio Output | ||
| HDMI/VGA output: | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz | |
| Recording Resolution: | 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
| Frame Rate: | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) | |
| Audio Output: | 1-ch, RCA (Linear, 1kΩ) | |
| Synchronous Playback: | 8-ch | |
| Decoding | ||
| Live view / Playback: | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
| Capability: | 5-ch@1080P | |
| Hard Disk | ||
| SATA: | 2 SATA interfaces for 2 HDDs | |
| Capacity: | Up to 4TB for each disk | |
| External Interface | ||
| Network Interface: | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface | |
| USB Interface: | 1 × USB 2.0 and 1 × USB 3.0 | |
| Alarm In: | 4-ch(optional) | |
| Alarm Out: | 1-ch(optional) | |
| POE | ||
| Interface: | 8 independent 100 Mbps PoE network interfaces | |
| Max. Power: | 120W | |
| Supported Standard: | AF and AT | |
| General | ||
| Power Supply: | 100~240VAC | |
| Consumption(without hard disk and POE): | ≤ 10W | |
| Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) | |
| Working Humidity: | 10 % ~ 90 % | |
| Chassis: | 19-inch rack-mounted 1U chassis | |
| Dimensions: | 445 × 290 × 45mm (17.5 ×11.4 × 1.8 inch) | |
| Weight(without HDD): | ≤ 1 Kg (2.2 lb) | |
